Pneumatic Piston Pump

• Notice book (1) The max air pressure is 0.7Mpa. If the air pressure is too high, the tool is easy to be damaged to shorten the longevity of the tool. (2) Shut the air source after work or not work for a long time, then release the air in the tool. The user will responsible for the situation if the air compressor is not shut down. (3) Try your best to prevent the tool running freely in case of affecting the longevity of the tool. (4) The tool is not suitable for gasoline, kerosene, and liquid which have chemistry melt power. Do not clean the machine with gasoline. • Technical characteristic (1) Tool weight------5kg (2) Max air pressure------0.7Mpa (3) Air pressure------0.63Mpa (4) Discharge capacity------55L/min(water) (5) Whorl connector------G3/4” (6) Hose diameter------10mm

Products Details

Made with a robust structure, the motor body is made with either alloy metal. The Pneumatic Piston Pump Ideal for delivering fuel to oil burners as well as to take out water or oil from drums or other containers.  Furnished air valve cock and air hose nipple, however, the related drum joint and pipe for the drum can be sold separately. Pneumatic Piston Pump is driven by compressed air. It can be used in extracting or inputting lubricant from barrel. The part which connects with liquid is made of Aluminum, other Seal part of the tool is made of NBR. This tool does not apply to the liquid which can dissolve these two materials. Application : for transferring oils or liquids of any kind on ship, delivering fuel to oil burners as well as to take out water or oil from drums or other containers
DESCRIPTION UNIT
PISTON PUMP PNEUMATIC, W/DRUM JOINT & PIPE COMPLETE SET
PISTON PUMP PNEUMATIC PCS
DRUM JOINT & PIPE, FOR PISTON PUMP SET
